Final and Most Successful Locomotive
The final and most successful steam locomotive class was the BB18.1/4". It was first delivered in July 1951 and when No 1089 entered service in March 1958, it was the last mainlline steam locomotive built in Australia. Some are still restored and running excursions today.
Dimensions
The locomotive dimensions are as follows:
Length of Locomotive 1450mm
Length of Tender 875mm
Width 345mm
Height 475mm
Driving Wheel Diameter 162mm
Dimensions
The locomotive dimensions are as follows:
- Length of Locomotive 1450mm
- Length of Tender 875mm
- Width 345mm
- Height 475mm
- Driving Wheel Diameter 162mm
Individual parts will be available on this site soon. For the moment, please print our order form to purchase individual parts.
|
Q.G.R. BB18.1/4 5" gauge 4-6-2 Locomotive
|
||
| H1400 | Set of Drawings - 10 in Set | Contact us for Current Component Prices |
| H1401 | Front Bogie Wheel CI. 4 req. wt.180 gm | |
| H1402 | Front Bogie Axle Box CI. 1 req. wt.1.8 kg | |
| H1403 | Cylinder CI. 2 req. wt. 7.5 kg | |
| H1404 | Front Cylinder Cover CI. 2 req. wt. 300 gm | |
| H1405 | Rear Cylinder Cover CI. 2 req. wt. 600 gm | |
| H1406 | Front Piston Valve CI. 2 req. wt. 200 gm | |
| H1407 | Rear Piston Valve Cover CI. 2 req. wt.500 gm | |
| H1408 | Piston Gland PB. 2 req. wt. 100 gm | |
| H1409 | Eccentric Strap CI. 2 req. wt. 275 gm | |
| H1410 | Manifold PB. 1 req. wt. 500 gm | |
| H1412 | Drive Wheels CI. Set of 6. wt. 9 kg | |
| H1414 | Driver Axle Boxes CI. 2 sticks req. wt. 2.4 kg | |
| H1416 | Driver Brake Blocks CI. 1 Ring req. wt. 900 gm | |
| H1417 | Trailing Truck Axle Box CI. 2 req. wt. 500 gm | |
| H1418 | Sand Box and Lid CI. 1 req. wt. 1 kg | |
| H1419 | Smoke Box Ring PB. 1 req. wt. 1 kg | |
| H1420 | Smoke Box Door PB. 1 req. wt. 1 kg | |
| H1421 | Chimney PB. 1 req. wt. 1 kg | |
| H1422 | Steam Dome Top PB. 1 req. wt. 900 gm | |
| H1423 | Steam Bush PB. 1 req. wt. 1 kg | |
| H1424 | Front Bogie Support CI. 1 req. wt. 1 kg | |
| H1425 | Motion Bracket PB. 2 req. wt. 600 gm | |
| H1426 | Loco Axle Pump PB. 2 req. wt. 450 gm | |
| H1427 | Smoke Box Saddle CI. 1 req. wt 1.6 kg | |
| H1428 | Girder Support PB. 1 RH 1 LH req. wt. 400 gm | |
| H1429 | Loco Brake Cylinder PB. 2 req. wt. 750 gm | |
| H1430 | Motion Girder PB. 2RH 2LH req. wt. 525 gm | |
| H1431 | Tender Axle Boxes CI . 2 sticks of 4 req. wt. 1.75kg | |
| H1432 | Regulator PB. 1 req. wt. 500 gm | |
| H1433 | Regulator Yoke PB. 1 req. wt. 80 gm | |
| H1434 | Tender Horns PB. 4 sticks of 4 req. wt. 2.7 kg | |
| H1435 | Regulator Bush PB. 1 req. wt. 750 gm | |
| H1436 | Tender Brake Blocks CI. 1 ring req. wt. 800 gm | |
| H1437 | Tender Wheels CI. 8 req. wt. 1.0 kg | |
| H1438 | Tender Bogie Centre Bottom CI. 2 req. wt. 300 gm | |
| H1439 | Tender Bogie Centre Top CI. 2 req. wt. 400 gm | |
| H1440 | Tender Side Bearer CI. 4 req. wt. 50 gm | |
| H1441 | Tender Brake Cylinder Complete PB. 1 req. wt. 800 gm | |
| H1644 | Muffler PB. lost wax 1 req. wt. 300 gm | |
| H3468 | Tender D.A. Hand Pump PB. 1 req. wt. 1.0 kg | |
| H1401 | Trailing Truck Wheel CI. 2 req. wt. 180 gm | |
| H1611 | Buffer Stock CI. 4 req. wt. 180 gm | |
| H1415 | Driving Wheel Tyres MS Set of 6 req. wt. 10.5 kg 180x125x20 | |
| H1413 | Locomotive Frames Precision Water-jet Cut | |
| H1499 | Complete Set of 88 Castings wt. 58 kg | |
